BD53-60, 60W Price:¥

Online inquiry
Details Specifications Remark

 Brush type DC motor in nominal power 60W

 Special voltage windings available on request

 Different shaft size available for both sides on request

 Motor shaft with ball bearing

 Protection class IP50, higher class available on request

 Longer lifetime, maintenance-free, insulation class E

BD53-60-flyer.pdf


Nominal voltage

24 VDC

Torque constant

6.2 Ncm A-1

Nominal current

2.9 A

Terminal resistance

1.05 Ω

Nominal torque

17 Ncm

Terminal inductance

4.7 mH

Nominal speed

3000 rpm

No load current

0.2 A

Stall torque

143 Ncm

Rotor inertial

460 gcm2

No load speed

3250 rpm

Weight of motor

1.16 kg
